AM965 Manual Switch

4 HP | AM965 Manual Switch | User Manual (PDF) | Modular Grid | You Tube

DESCRIPTION The AM965 Module is a dual analog switch with manual push button control. A simple but very useful design for controlling audio and CV signals by the push of a button.

The module contains two bi-directional analog switches that can be used either as 2x inputs and 1x output, or  1x input and 2x outputs. The switches are toggled on and off by a high quality manual push button at the base of the module (blue cap). The switch status is shown by a pair of red and green LED's for each switch.

The analog switches can control audio or CV signals, up to 20V p-t-p.

CONNECTIONS For each analog switch there are three jack sockets; A, B and C. There is a green LED that indicates when A is connected to C, and a red LED that indicates when B is connected to A.

The module comes with a 10-pin power cable, a set of black M3x8mm mounting screws and washers.

PRODUCT STATUS: IN PRODUCTION
